Phase contrast inverted microscope
Phase contrast inverted microscope
Incorporates all the features of an International Microscopes for professionals.This Research microscope is essential when it comes to examination of living micro-organism, cells etc., permitting observation of the internal structure of such specimens under different degree of contrast. We are suppliers of Phase Contrast Binocular Microscopes.
Specifications:
| Minimum Order Quantity | 1 Piece |
| Brand | LABPRO |
| Model | PHHL-6A |
| Is It Portable | Portable |
| Eyepiece | Keowa H6 X And Hkw 10 X (Paired) & One Centering Telescope Eyepiece |
| Illumination | Built-in Base Illumination With 6 V-20 W Halogen Lamp & Intensity Controlled Power Supply |
| Stand | Rigid & Heavy Single Mold Aluminum Die-cast Stand |
| Nosepiece | Quadruple Ball Bearing Nosepiece With Positive Click Stop & Rubber Grip |
| Objectives | Achromatic Objectives 4x/na 0.10Ph, 10 X/na 0.25Ph, 40 X/na 0.65(Sl)Ph & 100x/na1.25(Sl, Oil Imm) Ph |
| Tension Control Ring | Enable You To Adjust Tension On Coarse Focusing Knobs |
| Electricals | Built-in Transformer With Universal Input 100 V-240 V AC |
Incorporates all the features of an International Microscopes for professionals.This Research microscope is essential when it comes to examination of living micro-organism, cells etc., permitting observation of the internal structure of such specimens under different degree of contrast. We are suppliers of Phase Contrast Binocular Microscopes.
Specifications:
- Observation Head: BINOCULAR or TRINOCULAR head inclined at 45o and rotatable in 360o lockable at any angle. Both eyepiece tubes focusable to match objectives tube length. Interpupillary distance adjustments provided.
- Stage: MECHANICAL stage( Ball Bearing Type) of size 120 x 140 mm having low positioned co-axial controls. Both X & Y axis having graduated scale & verniers reading to 0.1 mm.
- Focusing: MECHANICAL stage( Ball Bearing Type) of size 120 x 140 mm having low positioned co-axial controls. Both X & Y axis having graduated scale & verniers reading to 0.1 mm.
- Focusing: Co-axial fine & coarse focusing control with ball bearing guideways based on four stage gear reduction system, free from any back lash & large knobs provide a soft & sophisticated touch to the microscope.
- Condenser: Focusable Abbe two lens type condenser NA 1.25 fitted with iris diaphragm and swing out filter holder with blue filter moving up and down through rack and pinion mechanism.
- Phase Contrast Attachment: Phase Annular Rings built inside matching with annular Phase plates provided in a substage condenser having a turret to bring in position the required Phase Rings suitable for the particular objective which is in position.
- Packaging contents: Packed in shockproof Styrofoam molded box or in a plywood cabinet having provision for placing eyepieces, objectives.Nylon Dust cover. Detachable power cord and 3-pin plug.
- Warranty Information: 2 Years parts. 1 year Electronics.
Additional Information:
- Delivery Time: 3-4 Days
- Packaging Details: Packed in foam styro box or in wooden box with standard accessories
$744.31
