Microprocessor Fully Automatic Photo Colorimeter

Microprocessor Fully Automatic Photo Colorimeter Model No. 030-G is a compact and easy to operate instrument for Photo Colorimeter analysis of any concentration. The output is available on a 3 digit seven segment bright red LED display in terms of %Transmission (%T), Optical Density (O.D). This instrument has the facility for auto zeroing of Absorbance and setting 100% Transmission. The use of microcontroller has made it extremely versatile and state-of-the-art instrument. 10 mm pathlength matched test tubes are used for sample and blank.

The instrument operates at wavelength between 400 to 700 nm range. The use of high standard wide range glass filters covering 400 to 700 nm in the monochromator gives extremely good results. The filter setting is controlled by a rotating disc having 8 filters. An automatic shutter is provided to stop the light reaching the sensor, when test tube is not inserted in the tube holder. This increases the life of sensor tremendously.

Salient Features



·       Highly Accurate and Stable



·       Auto Zero Facility



·       Compact & easy to operate



·       Soft Touch membrane keys



·       1 ml sample size



·       Microprocessor Based Technology



·       Set Wavelength with soft touch keys



Technical Specifications
Range	400-700nm
Filters	Built in 8 Digital Filters-30000 Hours life
Filters Wavelength	400nm, 420nm, 480nm, 500nm, 520nm, 540nm, 620nm, 700nm
Optical Density	0 to 1.99 O.D.
Accuracy	±0.01 O.D.
Stability	±0.02 O.D. Per Hour
Display	16 x 2 Alphanumeric LCD Display
Display Mode	Optical Density (O.D.) & Transmission
Detector	Silicone Photo Diode
Zero Adjustment	Auto Zero by Soft Touch Membrane Key
Light Source	Highly Accurate Laser Source
Amplifier	Microprocessor Based
Sample Volume	1 ml Minimum
Dimension	230x195x95 mm
Weight	1.5 Kgs. (Approx.)
Power	230V ± 10% AC, 50Hz
ACCESSORIES	1) A Set of 5 Matched Test Tubes   2) Tube Stand   3) Dust Cover   4) Instruction Manual
