Metronix Auto Refractometer
Metronix Auto Refractometer
Model No. R 20 +
- Refractive Measuring Range: Sph: + 25D /Cyl : + 10D(0.12D or 0.25D step), Axis: 1~ 180 degree( 1 degree step)
- Measurement Mode: Automatic or Manual (selectable from Monitor) IOL
- Vertex Distance: 0,12,13.5 or 15 mm (selectable)
- Min. Measurable Pupil Diameter: Ø 2.00 mm
- Measurable Papillary Distance(PD): 30 ~ 85 mm( 1 mm step), Automatic
- Fixation Target: Scientifically designed auto-fogged scenic picture
- Printer: Fast thermal printer with easy paper load facility
- Internal Monitor: 5.7inch bright color LCD monitor
- Shifting Range: Back & forth : ±19 mm, right & left : ±44 mm, Up & dn : ±19 mm, Chin & rest : ±30 mm,
- Power Saving Function: OFF /5 min or 15 min(selectable)
- Data Transmission: RS-232C interface (For Auto phoropter)
- Power Source / Consumption: 110~240V AC. 50~60Hz /60 VA
- Dimensions / Weight: 288(W) X 500(D) X 480(H) mm/14 kg
- Quality Certification: CE & ISO 9001: 2000
Other Details:
- Dual CCD Camera technology with 5.7inch and hi-resolution color LCD display.
- Its provide an accurate and wide measuring range with its two selected mode ie. Auto & manual mode of measurement.
- Both corneal curvature in mm and corneal power in Diopter is available.
- Scientifically designed scenic Fixation target with auto fogging technology can even measure smallest pupil of 2mm size.
- On-screen display of 10 measurement per eye with PD & average data for subjective test.
- Easy one key locking knob which help to prevent un-wanted movement over base during intermittent use.
- As per user choice there is a friendly parameter settings .
- It is built with reliable and fast thermal printer with easy paper loading features.
- Latest SMPS power supply system which allows working perfect even at low voltage or fluctuating supply voltage.
- It is compatible with MATRIX CV-7000,auto vision tester(Auto phoropter).
|
Escrow is safe for buyers and sellers, we recommend you to choose Escrow,it supports Credit card,
Money bookers, Visa, Master-card, Western union etc.
If you need to use "other" payments,please contact us ,via mail or message.
Payment should be finished within 7 days, if have some difficult, please notify me.
We only ship to your confirmed address. Please make sure your shipping address is co |
